ICD-U80 In-Circuit Programmer/Debugger

Sku: 53506-1648

ICD-U80 In-Circuit Programmer/Debugger
In stock (ships immediately)
$119.00

Note: This product replaces the ICD-U64.

ICD-U80 is a complete In-Circuit Programming and In-Circuit Debugging solution for Microchip's PIC® MCUs and dsPIC® DSCs. ICD-U80 debug support covers all targets that have debug mode when used in conjunction with the C-Aware IDE Compilers. The unit also provides in-circuit serial programming (ICSP™) support for all Flash chips.

IDE Screenshot
Data Streaming

ICD-U80 Advantages:

  • Accelerated programming speed using a 140MHz internal processor
  • Integrated Vdd generator to supply 1.5-5.5V and 400mA to target
  • Software controlled power to target - no jumpers to change
  • Fully integrated with the CCS C-Aware IDE or can be used stand-alone
  • Programming and debugging support for Microchip PIC® MCU, dsPIC® DSCs, & flash devices
  • Programming support for Microchip PIC32 and 8-bit AVR® microcontrollers (HVSP interface is not supported)
  • Powers and connects with USB
  • Includes FREE CCSLOAD Software
  • Data Streaming - Obtain real-time diagnostic data, and more...
  • RoHS compliant

Computer Requirements: CCS device programmers only work with 32 or 64-bit Windows on Intel®, AMD or Arm® processors, or with Linux on Intel® or AMD processors.

CCSLOAD FREE programmer control software supports the ICD-U80 and offers many new key features including; powerful command line options in Windows/Linux, extensive diagnostics, easy to use production interface, and enhanced security options.

  • Easy to use GUI interface
  • Include configuration fuses in the programming
  • Optionally can verify hex file CRC's to ensure the file was not corrupted
  • Optionally can verify chip is actually read protected after programming
  • Can program encrypted hex files to reduce the chance of reverse engineering
  • Serial numbering and logging built into the software

Connection to your target chip is easy using universally accepted connections:

Click here for target connection details.
